美国SANDPIPER气动双隔膜泵功能特点：
接口尺寸Port Size
3/4" NPT (内螺纹Internal)
1-1/2" NPT (外螺纹External)
流量Capacity
0-87 lpm升每分钟
气阀Air Distribution Valve
No-lube, no-stall design免润户，无卡死设计
可通过固体颗粒物直径Solids-Handling
4 mm
扬程Heads Up To
100 psi or 231 ft. of water (7 bar or 70 meters)
大工作压力Max Operating Pressure
100 psi (7 bar)
运输质量Shipping Weight
Polypropylene: 8 kg
PVDF: 9.5 kg



常用型号：
S07B1P1PPNS000
S07B1P2PPNS000
S07B1K1KPNS000
S07B1K2KPNS000
如有其它型号，欢迎来电咨询！
